Switching 25A + cargador (2 salidas). Voltaje 4-16V

Specification

• Input Voltage: AC 90~125 or AC 200~240 inside selectable

• Output Voltage: AV-825-BCM / DC 4.0V~16V variable

• Output Voltage Regulation: Less than 1%

• Ripple: Less than 9 mVp-p at rated load

• Dimentions (L·W·H): 165 X 147 X 55 mm

• Weight: 1.4 Kg

Protection:

• Short Protection, Short Protection & Over Voltage Protection >16V:

• It will reduce the output voltage down to 0.1v Amps down to 0.4Amps and

• the warning led will light up. When short condition, removing it will

• automatic restart the power supply to normal condition.

• Over Temperature Protection

• AV-825-BCM Series has double stage over temperature protection

Output Current

• AV-825-BCM Max 25 Amps continuous 22 Amps

• Battery Back current 15 Amps intermittent OR 4 Amps continuous

EAN:8435757700903
