TRIPLE-MAG- Komunica reinforced magnet base Maximum grip
Diameter: 3pcs x 9cm
Connector: SO-239
Cable RG-58 (5mts)
Frequency Range:
DC~3GHz
Power Range:
Dc~30MHz 2KW
30MHz~200MHz 1KW
200MHz~500MHz 500W
500MHz~1GHz 250W
1GHz~3GHz 150W
Insertion Loss:
Dc~500MHz <=0.05dB
500MH~1GHz <=0.10dB
1GHz~2GHz <=0.15dB
2GHz~3GHz <=0.20dB
Output Port 1/2 Isolation:
Dc~500MHz >=70dB
500MH~1GHz >=60dB
1GHz~2GHz >=55dB
2GHz~3GHz >=50dB
VSWR:
Dc~500MHz <=1.10
500MH~1GHz <=1.15
1GHz~2GHz <=1.20
2GHz~3GHz <=1.25
Connector Type:
Input Port 1 "N" Female
Output Port 2 "N" Female
EAN:8435757707728
