General
Number of channels |
: |
40 |
Modulation modes |
: |
AM/FM |
Frequency ranges |
: |
from 26,965 MHz to 27,405 MHz |
CTCSS |
: |
38 tones |
DCS |
: |
104 codes |
Antenna impedance |
: |
50 ohms |
Power supply |
: |
7.4 V (Handheld configuration) / 13.2 V (Mobile configuration) |
Size |
: |
152 (H) x 66,5 (L) x 37 (P) mm |
Weight |
: |
305 g with battery |
Loud speaker |
: |
8 ohms, 1 W |
Transmission
Frequency allowance |
: |
+/- 200 Hz |
Carrier power |
: |
4 W AM / 4 W FM |
Transmission interference |
: |
inferior to 4 nW (- 54 dBm) |
Audio response |
: |
300 Hz to 2,5 KHz |
Emitted power in the adj. channel |
: |
inferior to 20 μW |
Microphone sensitivity |
: |
7 mV |
Drain |
: |
1,8 A max. |
Modulated signal distortion |
: |
2 % |
Reception
Maxi. sensitivity at 20 dB sinad |
: |
0.5 μV - 113 dBm AM / 0.35 μV - 116 dBm FM |
Frequency response |
: |
300 Hz to 3 kHz |
Adjacent channel selectivity |
: |
60 dB |
Maximum audio power |
: |
1 W |
Squelch sensitivity |
: |
min. 0,2 μV - 120 dBm / max. 1 mV - 47 dBm |
Frequency image rejection rate |
: |
60 dB |
Intermediate frequency rej. rate |
: |
70 dB |
Drain |
: |
Mode ECO |
