Frequency: 26-28 MHz
Installation Version
General
Number of channels | : | 40 |
Modulation modes | : | AM/FM/USB/LSB |
Frequency ranges | : | from 26.965 MHz to 27.405 MHz |
Antenna impedance | : | 50 ohms |
Power supply | : | 12 V |
Size | : | 185 (W) x 172 (D) x 56 (H) mm |
Weight | : | 1.190 kg |
Accessories supplied | : |
power cord with fuse 1 microphone UP/DOWN and its hanger 1 mounting bracket with fixing screws |
CTCSS | : | 38 tonos |
DCS | : | 104 codes |
Transmission
Frequency allowance | : | +/- 200 Hz |
Carrier power | : | 4 W AM / 4 W FM / 12 W PEP USB LSB |
Transmission interference | : | inferior to 4 nW (- 54 dBm) |
Audio response | : | 300 Hz to 3 kHz AM/FM/USB/LSB |
Emitted power in the adj. channel | : | inferior to 20 μW |
Microphone sensitivity | : | 3.0 mV |
Drain | : | < 5 A max. with modulation (13.2V) |
Modulated signal distortion | : | 2 % |
Reception
Maxi. sensitivity at 20 dB sinad | : |
0.5 μV -113 dBm (AM) 0.35 μV -116 dBm (FM) 0.28 µV -118 dBm (USB LSB) |
Frequency response | : | 300 Hz to 3 kHz AM/FM |
Adjacent channel selectivity | : | 60 dB |
Maximum audio power | : | 3 W |
Squelch sensitivity | : | minimum 0.2 μV - 120 dBm / maximum 1 mV - 47 dBm |
Frequency image rejection rate | : | 60 dB |
Intermediate frequency rej. rate | : | 70 dB |
Drain | : | 200 ~ 600 mA max (13.2 V) |
