Switching power supply 25A with noise filter & instruments. Output voltage regulable from 4,0V-16V (DC).
Switching Power Supply, 25A continuos + DIGITAL PANEL. Extraflat version.
Add to compare0
Add to wishlist(1)
Specifications
Output Current |
Máx 25 amps, continuos 22 amps |
Input Voltage |
AC 90~125 or AC 200~240 inside selectable |
Output Voltage |
AV-825-DP DC 0.5V~16V |
Output Voltage Regulation |
Less than 1% |
Ripple |
Less than 9m VP-P with nominal load |
Dimentions (L·W·H) |
165 X 147 X 55 mm |
Weight |
1.2 Kg |
Protection
Short circuit protection |
It will reduce the output voltage to 0.1VA down to 0.4A and the warning light will turn on when this condition is removed. It will automatically reset the power supply to its normal condition |
|
Overload protection |
Same as above |
|
Overvoltage protection (if it exceeds DC 16V) |
Same as above |
|
Overheat protection |
AV-800-DP series has two-stage overheat protection function |
Output Current
AV-825DP: Max 25 amps, continuous 22 amps
EAN:8435757700910
