The A99 features the Solarcon
in Ring Adjust-A-Match tuning making it possible to tune the input to the antenna and obtain the optimum S.W.R. over a range of frequencies. Raising the rings raises the frequency and lowering the rings lowers the frequency.
High: 5,35m
Remember to improve the performance of your A-99 antenna by adding the optional GPK-1 ground plane
Electrical Data:
-
Type: 5/8 λ ground plane
-
Radiation: Omnidirectional
-
Polarization: Linear vertical
-
Frequency range: 26 ... 28 MHz Tunabl
-
Systems: 10m-HAM
-
Gain: 1.5 dBd, 3.65 dBi
-
Max Power: 1000 Watts (CW) continuous / 3000 Watts (CW) short time
-
Grounding protection: DC-Ground
-
Connector: UHF-female (SO-239)
Mechanical Data:
-
Height (approx): 6700 mm / 21.98 ft
-
Materials: Aluminium, Copper, Galvanized steel, Nylon
-
Weight (approx): 6000 gr / 13.23 lb
-
Mounting type: On-Mast
