General
Number of channels | : | 40 |
Modulation modes | : | AM / FM |
Frequency ranges | : | from 26.965 MHz to 27.405 MHz |
Antenna impedance | : | 50 ohms |
Power supply | : | 12 V |
Size | : | 125 (W) x 151 (D) x 45 (H) |
Weight | : | 0.9 kg |
Accessories supplied | : | Ultra light electret microphone with support mounting cradle screws |
Filter | : | ANL (Automatic Noise Limiter) built-in |
Transmission
Frequency allowance | : | +/- 200 Hz |
Carrier power | : | 4 W AM / 4 W FM |
Transmission interference | : | inferior to 4 nW (- 54 dBm) |
Audio response | : | 300 Hz to 3 KHz |
Emitted power in the adj. channel | : | inferior to 20 μW |
Microphone sensitivity | : | 7 mV |
Drain | : | 1,7 A (with modulation) |
Modulated signal distortion | : | 2 % |
Reception
Maxi. sensitivity at 20 dB sinad | : | 0.5 μV - 113 dBm AM / 0.35 μV - 116 dBm FM |
Frequency response | : | 300 Hz to 3 kHz |
Adjacent channel selectivity | : | 60 dB |
Maximum audio power | : | 2.5 W |
Squelch sensitivity | : | minimum 0.2 μV - 120 dBm / maximum 1 mV - 47 dBm |
Frequency image rejection rate | : | 60 dB |
Intermediate frequency rej. rate | : | 70 dB |
Drain | : | 160 ~ 420 mA |
