General
Modulation modes |
: |
AM / FM / USB / LSB / CW |
Frequency ranges |
: |
continuous scanning of 24.890 Mhz to 24.990 Mhz and of 28.000 Mhz to 29.700 Mhz |
CTCSS |
: |
38 tones |
DCS |
: |
104 codes |
Antenna impedance |
: |
50 ohms |
Power supply |
: |
12 V |
Size |
: |
170 (W) x 250 (D) x 52 (H) |
DIN Size |
: |
|
Weight |
: |
1,4 kg |
Accessories supplied |
: |
power cord with fuse1 microphone UP/DOWN and its hanger1 mounting bracket with fixing screws |
Transmission
Frequency allowance |
: |
+/- 300 Hz |
Carrier power |
: |
50 W AM (PEP) / 35 W FM / 35W USB-LSB (PEP) / 12W CW |
Transmission interference |
: |
inferior to - 50 dBc |
Audio response |
: |
300 Hz to 3 KHz in AM/FM/USB/LSB |
Emitted power in the adj. channel |
: |
inferior to 20 µW |
Microphone sensitivity |
: |
3,0 mV |
Drain |
: |
6 A (with modulation) |
Modulated signal distortion |
: |
2 % |
Reception
Maxi. sensitivity at 20 dB sinad |
: |
0.7 µV - 110 dBm (AM) / 0.35 µV - 116 dBm (FM) / 0.28 µV - 118 dBm (USB/LSB/CW) |
Frequency response |
: |
300 Hz to 3 kHz in AM/FM/LSB/USB |
Adjacent channel selectivity |
: |
60 dB |
Maximum audio power |
: |
3 W |
Squelch sensitivity |
: |
minimum 0.2 µV - 120 dBm / maximum 1 mV - 47 dBm |
Frequency image rejection rate |
: |
60 dB |
Intermediate frequency rej. rate |
: |
70 dB |
Drain |
: |
400 mA nominal / 600 mA maximum |
